Stahlwille 41614850 - Double Open End Wrench SW 1 x 1 1/16 L.368mm

flat elbow

Characteristics

• A special manufacturing process allows for the production of thin-walled rings that are thin enough for use in confined spaces, yet robust enough to withstand heavy loads.
• The 12-sided AS-Drive profile protects screws and nuts, as force is specifically applied through the flanks, and not through the edges.
• STAHLWILLE's distinctive rounded finish gives the combination wrench and ring a pleasant, non-slip feel for safe working, even with oily hands.
• Made from high-performance HPQ® steel and with an additional chrome coating for increased durability, reliable corrosion protection and enormous wear resistance.
• Different sized ends, imperial system, flat toothed, 12 faces with AS-Drive profile, durable, slim and lightweight design, high bending strength thanks to the double Tel profile, STAHLWILLE rounded finish ensures a pleasant and non-slip feel, HPQ® high-performance steel, chrome plated, SAE AS 954 (dimension and check values) / Fed. Spec. GGG-W-636 E / SBAC Techn. Spec. TS 48 to 1/2"
• Width of planes 1 [inch]: 1 "
• Plane width 2 [inches]: 1 1/16"
• Length mm (L): 368 mm
• a1: 15 mm
• a2: 16 mm
• Output profile: 12-sided AS-Drive
• d1: 36.5 mm
• d2: 38.6 mm
• Alloy: HPQ® high-performance steel
• Surface: chrome-plated
• t1: 23 mm
• t2: 24 mm
• Ring position: 10°
• Weight (g): 460 g
• Weight in kg: 0.46 kg
